| model | LSPA8-120 |
| Type | 1GANG,2GANG,3GANG,4GANG |
| Operation type | WiFi |
| Standard | US/Australian/Brazilian/Vietnam |
| Method | Without monitor function |
| Connection | N+L or L |
| Support system | IOS and Android |
| Color | Black/white/golden |
| Maximum current | 16A |
| maximum power | 300W/gang |
| Input voltage | AC100-240V 50/60Hz |
| Maximum load current | 16A |
| Material | high quality flame retardant PC+tempered glass panel |
| Wifi standard | 2.4gHz 802.11b/g/n(2400M-2483.5M) |
| Standby power consumption | 0.5W/Hour |
| Function | Remote control, smart timing/delay, status feedback, power-off memory, voice control, sharing function, smart scene control, touch switch |
| Indicator light | Red and blue(red is the power light, blue is the wifi light) |
| Shell material | High quality fireproof PC+tempered glass panel |
| Installation | Embedded(120type)US mounting box |
| Operating temperature | -20℃-500℃ |
| Certification standard | FCC/ROHS |
| Product size | 120*78*34mm |
| Colour box size | 100*90*45mm |
| Packing quantity | 50pcs |
| Outer box size | 425*295*235mm |
| Net weight | 197g |
| Gross weight | 233g |
| Net weight of outer box | 1gang=8.10kg,2gang=8.35kg,3gang=8.8kg,4gang=9.86kg |
| Gross weight of outer box | 1gang=11.65kg,2gang=12.05kg,3gang=12.35kg,4gang=12.35kg |
